Enhanced geothermal system

Résumé

An enhanced geothermal system (EGS) generates geothermal electricity without natural convective hydrothermal resources. Traditionally, geothermal power systems operated only where naturally occurring heat, water, and rock permeability are sufficient to allow energy extraction. However, most geothermal energy within reach of conventional techniques is in dry and impermeable rock. EGS technologies expand the availability of geothermal resources through stimulation methods, such as 'hydraulic stimulation'. Overview In many rock formations natural cracks and pores do not allow water to flow at economic rates. Permeability can be enhanced by hydro-shearing, pumping high-pressure water down an injection well into naturally-fractured rock. The injection increases the fluid pressure in the rock, triggering shear events that expand pre-existing cracks and enhance the site's permeability. As long as the injection pressure is maintained, high permeability is not required, nor are hy

Source officielle

https://en.wikipedia.org/wiki/Enhanced_geothermal_system

À propos de ce résultat

Cette page est générée automatiquement et peut contenir des informations qui ne sont pas correctes, complètes, à jour ou pertinentes par rapport à votre recherche. Il en va de même pour toutes les autres pages de ce site. Veillez à vérifier les informations auprès des sources officielles de l'EPFL.

Publications associées (7)

Publications associées

Chargement

Personnes associées (1)

Personnes associées

Chargement

Unités associées (2)

Unités associées

Chargement

Concepts associés (4)

Concepts associés

Chargement

Cours associés (4)

Cours associés

Chargement

Séances de cours associées (4)

Séances de cours associées

Chargement

Underground resources and sustainable urban development: the example of shallow geothermal potential mapping

Pascal Blunier, David Bréthaut, Aurèle Parriaux

2009

Chargement

This paper details the development of a systematic methodology using thermo-economic modeling that can be used to identify the optimal exploitation schemes of geothermal resources. A multi-period approach is used, integrating the superstructure of exploitable resources with the superstructure of conversion technologies and multiple demand profiles. In the example case, exploitable resources include an enhanced geothermal system, a deep aquifer, and a shallow aquifer. Power generating systems considered are organic Rankine cycles and both single and double flash steam cycles, which can be used for combined heat and power production. Heat pumps are also considered, as well as back up systems in case geothermal resources alone cannot fully satisfy demand. Periods considered for the demand profiles of district heating and cooling are summer, winter, inter-seasonal, and extreme winter and summer conditions. These are based on the city of Nyon, Switzerland for the example case. In the next step, process integration techniques are then used to design the overall geothermal system. The economic and thermodynamic performance of the system is then calculated. Finally, an evolutionary algorithm is employed to determine the optimal exploitation schemes and system configuration across the multiple periods, with exergy efficiency and annual profit as objectives.

2010

Chargement

Defining Optimal Configurations of Geothermal Systems Using Process Design and Process Integration Techniques

Léda Gerber, François Maréchal

The use of geothermal resources for the polygeneration of energy services has recently gained interest and is expected to know an important development in the future. Major research questions concern the increase of the efficiency in the usage of geothermal resources, as well as the increase of their economical profitability and the minimization of the generated life-cycle environmental impacts. This can be achieved by applying process design and process integration techniques to the overall geothermal system, formed by the subsystems of resources harvesting, energy conversion systems and demand. This paper presents a systematic methodology for the optimal design of geothermal systems configurations. In a first step, the different components of the system superstructure are separately modeled using a flowsheeting software. The superstructure includes not only the potential conversion technologies, but as well the different types of potential resources and the demand profiles for the district heating and cooling. It covers a wide pannel of conventional resources and technologies like deep and shallow aquifers, heat pumps, flash systems or organic Rankine cycles, as well as emerging resources and technologies, like Enhanced Geothermal Systems, Kalina cycles, supercritical cycles or organic Rankine cycles using fluid mixtures. Then, resources, technologies and demand profiles models are integrated together using process integration techniques. The resolution of the mixed integer linear programming problem extracts the configuration of the geothermal system from the superstructure. The state variables of the final configuration are then used to define the size of the equipment in the system. Based on these results, the economic, energetic and environmental performances of the integrated system are finally calculated. Performance indicators considered include energy and exergy efficiency, investment costs, operating costs and profitability. Life cycle impact assessment is as well performed by fully integrating the life cycle inventory in the process design framework. To account for the seasonal variation of the demand in energy services, a multi-period optimization model of the integrated system is proposed. The calculation sequence is implemented in a multi-objective optimization framework to calculate the optimal system configurations with their associated technologies, resources and process operating conditions, choosing the objective functions in the different considered performance indicators. This results into the thermo-economic Pareto Frontier that includes the set of the most attractive configurations of the system. The methodology is illustrated by an application to a case study of a city of Switzerland. The results are discussed, as well as their practical implications in terms of technological orientations to be favored in the development of geothermal energy.

Aidic Servizi Srl, Via Giuseppe Colombo 81/A, Milano, Mi 20133, Italy2011

Chargement

Defining Optimal Configurations of Geothermal Systems Using Process Design and Process Integration Techniques

Léda Gerber, François Maréchal

Aidic Servizi Srl, Via Giuseppe Colombo 81/A, Milano, Mi 20133, Italy2011
